KG-UV9D(Plus)
Share to:
DOWNLOAD : http://14442253.s21d-14.faiusrd.com/0/ABUIABBLGAAg2NmtzQUoyPHxogU?f=KG-UV9D%28Plus%29+setup.exe&v=1504406744
Detail


KG-UV9D(Plus)

MORE FUNCTIONS

Completely turn off display screen background light

mplitude-frequency PTT settings

Completely trun off flickering indicator light

ncoming Message Display Caller ID display

Dual Receiving

DTMF Encoding&Decoding

Duplex Work on A&B Areas (TX on one area while RX on the other area simultaneously)

All Calls,Group Calls And Selective Calls

RX on the same/different bands of A&B areas simultaneously

PriorRemote Alarmity Scan Function

Simultaneously Scanning on Twin Band, Scanning on Limiting Frequency

Wide/Narrow Bandwidth Selection (25KHZ/12.5KHz)

Channel Groups Scanning

Voice Guide:Chinese/English

Memory Channels 999

Chinese/English Screen Display

QT/DQT Encoding/Decoding,QT/DQT Scan

English Channel Name Edit

Non-Standard CTCSS can be set arbitrarily

Bright Flashlight illumination

VOX and SOS function

Single-Tone Pulse Frequency:2100Hz/ 1750Hz/1000Hz/1450Hz

Multi Definition for Sidekeys

Stopwatch

Reverse Frequency



  Frequency Range

  suitable for different countries or areas

  1 TX: 136-174MHZ(FM)

             400-512MHZ(FM)

   2 RX: 76-108MHZ(FM)

            108-136MHZ(air ground)

            136-180MHZ(FM)

            230-250MHZ(FM)

            350-400MHZ(FM)

            400-512MHZ(FM)

            700-985MHZ(FM)

  Step

2.5K/5KHz/6.25KHz/10KHz/12.5KHz 25KHz/50KHz/100KHz

  Channel Number

999

  Work Mode

F2D/F3E

  Operating Temperature

-20℃~+40℃

  Voltage

7.4VDC

  Antenna Impedance

50Ω

  Weight

490 g

  Size

123 x 58 x 31 MM


Transmitter

Wide

Narrow

  Adjacent Channel Selectivity

≥70dB

≥60dB

  Type of Modulation

16K F3E

11K F3E

  Spurious

≥60dB

≥60dB

  Audio Response

+1~-3dB(0.3~3KHz)

+1~-3dB(0.3~3KHz)

  Max Frequency Deviation

±5KHz

±2.5KHz

  Frequency Stability

±2.5PPM

  Audio Distortion

≤5%

  Output Power

UHF H:5W , M:2W , L:1W

VHF H:4W , M:2W , L:1W

Receiver

Wide

Narrow

  Adjacent Channel Selectivity

≤70dB

≤60dB

  Inter Modulation

≤65dB

≤60dB

  Spurious Response

≤70dB

≤70dB

  Audio Response

+1~-3dB(0.3~3KHz)

+1~-3dB(0.3~3KHz)

  Signal to Noise Ratio

≥45dB

≥40dB

  Audio Distortion

≤5%

  Audio Power

≤500mW

  Sensitivity

08-136MHz(AM) -106.0dbm SN 13dB

136-180MHz -119.0dbm SINAD 13dB

230-250MHz -116.0dbm SINAD 13dB

350-400MHz -119.0dbm SINAD 13dB

400-512MHz -119.0dbm SINAD 13dB

700-986MHz -96.0dbm SINAD 12dB

1.Dual Band , Cross Band Repeater , Large Color Screen
With two independent receivers for both UHF and VHF, you can listen to either the same or different bands simultaneously , large color screen can display more information

2.Seven Bands Reception and Dual Bands Transmission
Wider frequency ranges meet different demands. The frequency range is from 76MHz to 965MHz, including FM radio and air band

3.Classic Circuit , Excellent Performance
Mature circuit design and high quality electronic components, after years of use can still maintain stable performance

4.Using High Quality Plastic and Rubber Material
High quality plastic can make the shell more robust and durable good rubber material can make the button has a good touch feel
